Spacelabs Healthcare 92517 Capnography CO2 Module Mainstream / Sidestream

Spacelabs Healthcare 92517 Capnography / CO2 Module

Used medical equipment in used condition. The item may show cosmetic signs of previous use, including light marks, scuffs, scratches or other wear around the housing. Please review the photographs carefully, as they form part of the description.

Quantity available: 2
Price: £999.00 each + shipping

Product Details

• Manufacturer: Spacelabs Healthcare
• Model: 92517
• Device type: Capnography / CO2 module
• Monitoring modes: Mainstream and sidestream capnography
• Measures: End-tidal CO2 (EtCO2), minimum/inspired CO2 and respiratory rate
• Designed for use with compatible Spacelabs Healthcare patient monitoring systems

Technical Specifications

• CO2 measurement range: 0–120 mmHg (0–16 kPa), 0–15%
• CO2 resolution: 1 mmHg (0.1 kPa), 0.1%
• Typical measurement rise time: <200 ms
• CO2 accuracy: ±(0.2 vol% + 2% of reading)
• Respiratory rate range: 1–150 breaths/min
• Respiratory rate accuracy: ±1 breath/min
• Apnea range: 20–45 seconds
• Operating temperature: 0°C to 50°C
• Power: supplied by the compatible monitor
• CE marked

Please note: Two units are available. Serial numbers, software versions, manufacture dates and cosmetic condition may vary slightly between units. Please contact us before purchase if you require a specific unit or configuration.

Included:

1xSpacelabs 92517 module only, as shown.

Compatibility should be confirmed by the purchaser with their Spacelabs monitor, installed software and intended accessories before ordering.
